783-623

783-623
POTENTIAL-EQUILIZATION TB
Manufacturer Wago
SKU 783-623
MPN 783-623

Our price: $8.27

Please Contact Us for Stock Availability

Qty

Features

Approvals

  • American Bureau of Shipping, ABS, 20-HG1941090-PDA
  • DEKRA Certification B.V., KEMA/KEUR, 2187239.03, EN 60947
  • Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
  • Underwriters Laboratories Inc., UR, E45172, UL 1059
  • DEKRA Certification B.V., CCA, NTR NL-7456/A1, EN 60947

Specifications

Ratings Per Iec/En

  • Nominal voltage (III/3): 400 V
  • Rated surge voltage (III/3): 6 kV
  • Rated current: 68 A
  • Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

  • Connection technology: CAGE CLAMP®
  • Actuation type: Operating tool
  • Connectable conductor materials: Copper
  • Solid conductor: 0.2 … 16 mm² / 24 … 6 AWG
  • Fine-stranded conductor: 0.2 … 16 mm² / 24 … 6 AWG
  • Strip length: 16 … 17 mm / 0.63 … 0.67 inch
  • Wiring direction: Front-entry wiring

Physical Data

  • Width: 12 mm / 0.472 inch
  • Height: 88.5 mm / 3.484 inch
  • Depth from upper edge of DIN-rail: 43.5 mm / 1.713 inch

Mechanical Data

  • Design: Angled
  • Mounting type: DIN-35 rail
  • Marking level: Center marking

Material Data

  • Color: Gray
  • Flammability class per UL94: V0
  • Fire load: 0.461 MJ
  • Weight: 43.518 g

Commercial Data

  • Packaging type: Box
  • Country of origin Sales Organisation Germany: PL
  • GTIN: 4044918691475
  • Customs tariff number Sales Organisation Germany: 85369010000
