726-661

Features

Approvals

• DEKRA Certification B.V., KEMA/KEUR, 71-100850, EN 60998
• UL International Germany GmbH, UL, E45172, UL 1059
• DEKRA Certification B.V., CCA, NTR NL-7623, EN 60998
• DEKRA Certification B.V., CSA, 1101143, C22.2 No. 158

Specifications

Ratings Per Iec/En

• Rated current: 76 A
• Rated current 2: 24 A

Connection 1

• Connection type (1): Page 1
• Connection technology: Push-in CAGE CLAMP®
• Number of connection points: 1
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.2 … 16 mm² / 24 … 6 AWG
• Fine-stranded conductor: 0.2 … 16 mm² / 24 … 6 AWG
• Strip length: 16 … 17 mm / 0.63 … 0.67 inch
• Wiring direction: Front-entry wiring

Connection 2

• Connection type 2: Page 2
• Connection technology 2: CAGE CLAMP®
• Number of connection points 2: 2
• Solid conductor 2: 0.08 … 2.5 mm² / 28 … 14 AWG
• Fine-stranded conductor 2: 0.08 … 2.5 mm² / 28 … 14 AWG
• Strip length 2: 8 … 10 mm / 0.31 … 0.39 inch

Physical Data

• Width: 34.6 mm / 1.362 inch
• Height: 132 mm / 5.197 inch
• Depth: 80.7 mm / 3.177 inch

Mechanical Data

• Marking: 1 … 24
• Design: Slimline

Material Data

• Color: Dark gray
• Module color: White
• Fire load: 1.144 MJ
• Weight: 220.994 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055143628631
• Customs tariff number Sales Organisation Germany: 85369010000
