727-130/002-000

Features

Approvals

• DEKRA Certification B.V., CCA, NTR NL 7485, EN 60947
• DEKRA Certification B.V., KEMA/KEUR, 2192101.01, EN 60947
• DEKRA Certification B.V., CSA, 70048845, C22.2 No. 158

Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 250 V
• Rated surge voltage (III/3): 4 kV
• Rated current: 10 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
• Fine-stranded conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
• Strip length: 8 … 10 mm / 0.31 … 0.39 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 7.62 mm / 0.3 inch
• Height: 226 mm / 8.898 inch
• Depth from upper edge of DIN-rail: 58.5 mm / 2.303 inch

Mechanical Data

• Marking: A-b-c-d-e-f-g-h--h-g-f-e-d-c-b-a
• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Center marking

Material Data

• Color: Gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 1.187 MJ
• Weight: 75.000 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454187859
• Customs tariff number Sales Organisation Germany: 85369010000
